| Gauge Pattern (pattern number) |
Gauge Part Number (P/N) |
Gauge Grid
Dimensions
(L x W) in mm |
Gauge Backing
Dimensions
(L x W) in mm |
Gauge Creep Code * |
Grid Center
Distance (d) in mm |
|
41
|
ECH-200-4AA-(**)
ECI-200-4AA-(**)
ECH-200-6AA-(**)
ECI-200-6AA-(**)
ECH-200-8AA-(**)
ECI-200-8AA-(**)
ECH-350-2AA-(**)
ECI-350-2AA-(**)
ECH-350-2AA-A-(**)
ECH-350-3AA-(**)
ECI-350-3AA-(**)
ECH-350-4AA-(**)
ECI-350-4AA-(**)
ECH-350-5AA-(**)
ECI-350-5AA-(**)
ECH-350-6AA-(**)
ECI-350-6AA-(**)
ECH-350-8AA-(**)
ECH-350-10AA-(**)
ECH-500-4AA-(**)
ECH-500-6AA-(**)
ECH-650-4AA-(**)
ECI-650-4AA-(**)
ECH-650-5AA-(**)
ECH-650-6AA-(**)
ECH-1000-3AA-(**)
ECH-1000-6AA-(**)
|
4.0 x 2.0
4.0 x 2.0
6.0 x 2.3
6.0 x 2.3
7.8 x 3.0
7.8 x 3.0
2.4 x 3.2
2.4 x 3.2
2.2 x 3.0
3.1 x 3.0
3.1 x 3.0
4.0 x 2.4
4.0 x 2.4
4.8 x 3.1
4.8 x 3.1
6.4 x 3.4
6.4 x 3.4
7.5 x 5.4
10.0 x 4.8
4.0 x 3.3
6.0 x 3.3
4.2 x 4.2
4.2 x 4.2
5.0 x 3.5
6.2 x 4.5
3.2 x 4.8
6.0 x 5.0
|
9.0 x 4.0
9.0 x 4.0
10.7 x 4.0
10.7 x 4.0
11.0 x 6.0
11.0 x 6.0
6.4 x 4.6
6.4 x 4.6
4.5 x 4.0
7.4 x 4.4
7.4 x 4.4
8.2 x 4.2
8.2 x 4.2
9.3 x 4.6
9.3 x 4.6
10.4 x 5.4
10.4 x 5.4
11.2 x 7
13.8 x 6.6
8.2 x 5.1
13.2 x 5.8
8.6 x 6.0
8.6 x 6.0
9.0 x 5.6
10.4 x 6.4
7.4 x 7.4
10.0 x 6.3
|
|
|
|
42
|
ECH-350-3AB-(**)
ECI-350-3AB-(**)
ECH-350-4AB-(**)
ECI-350-4AB-(**)
ECH-350-6AB-(**)
ECI-350-6AB-(**)
ECH-350-8AB-(**)
ECI-350-8AB-(**)
|
4.5 x 3.7
4.5 x 3.7
5.5 x 4.8
5.5 x 4.8
8.5 x 6.8
8.5 x 6.8
11.2 x 8.8
11.2 x 8.8
|
8.2 x 5.9
8.2 x 5.9
10.0 x 7.0
10.0 x 7.0
12.1 x 10.0
12.1 x 10.0
15.0 x 11.0
15.0 x 11.0
|
|
|
|
43
|
ECH-350-3AC-(**)
ECI-350-3AC-(**)
ECH-350-4AC-(**)
ECI-350-4AC-(**)
ECH-350-6AC-(**)
ECI-350-6AC-(**)
ECH-350-8AC-(**)
ECI-350-8AC-(**)
|
4.5 x 3.7
4.5 x 3.7
5.5 x 4.8
5.5 x 4.8
8.5 x 6.8
8.5 x 6.8
11.2 x 8.8
11.2 x 8.8
|
8.2 x 5.9
8.2 x 5.9
10.0 x 7.0
10.0 x 7.0
12.1 x 10.0
12.1 x 10.0
15.0 x 11.0
15.0 x 11.0
|
|
|
|
44
|
ECH-350-3FB-(**)
ECI-350-3FB-(**)
ECH-350-4FB-(**)
ECI-350-4FB-(**)
ECH-350-6FB-(**)
ECI-350-6FB-(**)
|
3.1 x 3.0
3.1 x 3.0
4.0 x 2.4
4.0 x 2.4
6.4 x 3.4
6.4 x 3.4
|
7.4 x 7.6
7.4 x 7.6
8.2 x 6.8
8.2 x 6.8
11.0 x 9.0
11.0 x 9.0
|
|
|
|
45
|
ECH-350-2HA-D-(**)
ECI-350-2HA-D-(**)
ECH-350-3HA-D-(**)
ECI-350-3HA-D-(**)
ECH-350-4HA-D-(**)
ECI-350-4HA-D-(**)
ECH-350-6HA-D-(**)
|
2.0 x 4.2
2.0 x 4.2
3.1 x 3.8
3.1 x 3.8
4.0 x 3.3
4.0 x 3.3
6.0 x 9.7
|
8.8 x 5.6
8.8 x 5.6
8.8 x 6.8
8.8 x 6.8
8.2 x 8.2
8.2 x 8.2
11.0 x 11.3
|
|
|
|
46
|
ECH-350-2HA-E-(**)
ECI-350-2HA-E-(**)
ECH-350-3HA-E-(**)
ECI-350-3HA-E-(**)
ECH-350-4HA-E-(**)
ECI-350-4HA-E-(**)
|
2.0 x 4.2
2.0 x 4.2
3.1 x 3.8
3.1 x 3.8
4.0 x 3.3
4.0 x 3.3
|
8.8 x 5.6
8.8 x 5.6
8.8 x 6.8
8.8 x 6.8
8.2 x 8.2
8.2 x 8.2
|
|
|
|
47
|
ECH-350-2BB-(**)
ECI-350-2BB-(**)
ECH-350-3BB-(**)
ECI-350-3BB-(**)
ECH-350-4BB-(**)
ECI-350-4BB-(**)
ECH-350-6BB-(**)
|
2.2 x 2.8
2.2 x 2.8
3.0 x 3.4
3.0 x 3.4
4.0 x 4.3
4.0 x 4.3
5.8 x 6.5
|
8.0 x 6.0
8.0 x 6.0
8.8 x 6.8
8.8 x 6.8
10.0 x 7.8
10.0 x 7.8
14.4 x 10.0
|
|
|
|
48
|
ECH-350-2BB-A-(**)
ECI-350-2BB-A-(**)
ECH-350-3BB-A-(**)
ECI-350-3BB-A-(**)
ECH-350-4BB-A-(**)
ECI-350-4BB-A-(**)
ECH-350-6BB-A-(**)
|
2.2 x 3.3
2.2 x 3.3
3.0 x 3.1
3.0 x 3.1
4.0 x 4.2
4.0 x 4.2
6.0 x 6.1
|
7.7 x 6.0
7.7 x 6.0
8.4 x 6.8
8.4 x 6.8
10.0 x 7.8
10.0 x 7.8
14.0 x 10.0
|
|
|
|
49
|
ECH-350-2GB-(**)
ECH-350-3GB-(**)
ECH-350-4GB-(**)
|
2.2 x 3.0
3.1 x 3.0
4.0 x 3.4
|
10.8 x 4.4
12.6 x 4.4
15.2 x 5.8
|
|
|
|
50
|
ECH-350-2GB-AL-(**)
ECI-350-3GB-AL-(**)
|
2.2 x 3.0
3.0 x 2.9 |
10.8 x 4.4 |
|
|
|
51
|
ECI-350-2GB-AL-(**) |
2.2 x 3.0 |
10.8 x 4.4 |
|
|
|
52
|
ECI-350-(10)KA-(**)
ECI-350-(10)KA-(**)
ECI-350-(15)KA-(**)
ECI-350-(15)KA-(**)
ECH-350-(20)KA-(**)
ECI-350-(20)KA-(**)
|
Ø 9.0
Ø 9.0
Ø 14.0
Ø 14.0
Ø 19.0
Ø 19.0
|
Ø 10.0
Ø 10.0
Ø 15.0
Ø 15.0
Ø 20.0
Ø 20.0
|
|
|
